JY Series Table Type Steam Sterilizer


The sterilizer is a table type in safety and auto-controlled by computer, Which is designed for the unit of medical health, pharmacy, science and technology etc. And mostly suitable for sterilizing of surgical, dental and eye instruments, glassware medicine, culture medium and biological dressing, food and other goods.


  JY2001 Table Type Steam Sterilizer with Rapid Cooling System
  Main Technical Specifications:


Sterilizing chamber volume: 25L (¦µ270x410)
Maximum working pressure: 0.215Mpa
Max. working temperature: 134 o C
Adjustment of temperature: 115~134 o C
Timer: 0-60min
Chamber temperature equal: ¡Ü¡À1 o C
Source power: 1.5KW/ AC 220V 50HZ
Sterilizing plate: 290x190x 50mm
Overall size: 560x350x 500mm
Packing size: 620x410x 570mm
N/G.W: 18/ 19kg


  JY2002 Table Type Steam Sterilizer with Rapid Cooling System
  Main Technical Specifications:



Maximum volume: 20L (¦µ250x420)
Maximum working pressure: 0.215Mpa
Max. working temperature: 134 o C
Adjustment of temperature: 115, 121, 126, 134 o C
Timer: 0-60min
Chamber temperature equal: ¡Ü¡À1 o C
Source power: 1.5KW/ AC 220V 50HZ (1.5KW/AC 110V 60HZ)
Sterilizing plate: 290x190x 50mm
Overall size: 480x480x 384mm
Packing size: 720x580x 500mm
N/G.W: 38/ 43kg


  JY2003 Table Type Steam Sterilizer with Rapid Cooling System
  Main Technical Specifications:


Maximum volume: 20L (¦µ250x420)
25L (¦µ250x520)
Maximum working pressure: 0.215Mpa
Max. working temperature: 134 o C
Adjustment of temperature: 115~134 o C
Timer: 0-60min
Chamber temperature equal: ¡Ü¡À1 o C
Source power: 1.5KW/ AC 220V 50HZ (1.5KW/AC 110V 60HZ)
Sterilizing plate: 290x190x 50mm
Overall size: ( 20L ) 480x480x 384mm
( 25L ) 580x480x 384mm
Packing size: ( 20L ) 720x580x 500mm
( 25L ) 820x580x 500mm
N/G.W: 30/ 33kg

  JY2004 Table Type Steam Sterilizer with Rapid Cooling System

Main Technical Specifications:



Maximum volume: 35L
(¦µ300x500)
Maximum working pressure: 0.215Mpa
Max. working temperature: 134 o C
Adjustment of temperature: 115~134 o C
Timer: 0-60min
Chamber temperature equal: ¡Ü¡À1 o C
Source power: 2KW/ AC 220V 50HZ
Sterilizing plate: 290x190x 50mm
Overall size: 410x540x 460mm
Packing size: 720x650x 580mm
N/G.W: 38/ 45kg


  JY2005 Table Type Steam Sterilizer with Rapid Cooling System
  Main Technical Specifications:


Maximum volume: 20L (¦µ270x340)
Maximum working pressure: 0.215Mpa
Max. working temperature: 134 o C
Adjustment of temperature: 115~134 o C
Timer: 0-60min
Chamber temperature equal: ¡Ü¡À1 o C
Source power: 1.5KW/ AC 220V 50HZ
Sterilizing plate: ¦µ235x 255mm
Overall size: 360x350x 525mm
Packing size: 420x420x 630mm
N/G.W: 27/ 29kg

  JY2006 Table Type Steam Sterilizer
  Main Technical Specifications:


Maximum volume: 20L (¦µ270x340)
Maximum working pressure: 0.11Mpa
Max. working temperature: 121 o C
Adjustment of temperature: 105~121 o C
Chamber temperature equal: ¡Ü¡À1 o C
Source power: 1.5KW/ AC 220V 50HZ
Sterilizing plate: ¦µ235x 255mm
Overall size: 360x350x 525mm
Packing size: 420x420x 630mm
N/G.W: 27/ 29kg

  JY2007 Table Type Steam Sterilizer with Rapid Cooling System
  Main Technical Specifications:


Maximum volume: 50L (¦µ340x550)
Maximum working pressure: 0.215Mpa
Max. working temperature: 134 o C
Adjustment of temperature: 115~134 o C
Timer: 0~60min
Chamber temperature equal: ¡Ü¡À1 o C
Source power: 2.5KW/ AC 220V 50HZ (2.5KW/AC 110V 60HZ)
Sterilizing plate: 470x230x 75mm
Overall size: 750x600x 505mm
Packing size: 850x700x 680mm
N/G.W: 60/ 70kg

  JY2008 Table Type Steam Sterilizer with Rapid Cooling System
  Main Technical Specifications:


Maximum volume: 20L (¦µ250x420)
25L (¦µ250x520)
Maximum working pressure: 0.215Mpa
Max. working temperature: 134 o C
Adjustment of temperature: 115~134 o C
Timer: 0~999min
Chamber temperature equal: ¡Ü¡À1 o C
Touch-type setting of temperature, pressure and time
Self-control of temperature, pressure and time digital play (The display screen VFD)
Packing size: 720x580x 500mm
820x580x 500mm
N/G.W: 40/43kg
