DXDK100 Changeable cup-measuring method, suitable for packaging materials without photoelectric detection. The most distinct feature is the high packaging speed, which is comparable with the imported machine.

DXDK80 Adjustable cup-measuring method, with safe and creditable photoelectric detecting system, giving complete trademark pattern.

DXDK60 On the base of DXDK80, the packaging capacity has been enlarged to 50-100ml.

Packaging Material:
Paper/polyethylene, cellophane/polyethylene, polyester/plated aluminum/polyethylene, BOPP/polyethylene, aluminum-foil/polyethylene

Main Technical Specifications:

Type Capacity	DXDK100	DXDK80	DXDK60
Packaging speed (bag/min)	55-100	55-80	40-60
Range of measurement (ml)	1-10	10-50	50-100
Bag size (mm)	L: 40-80, W: 50-70	L: 50-120, W: 60-85	L: 80-145, W: 75-100
Source voltage	3-phase and four-wire system 380V/Hz
Power (Kw)	0.86
Weight (kg)	175
Dimension (mm)	LWH: 6257511558
