| 1. High seed and advanced design. 2. High-accuracy automatic bag packaging. 3. Stepless adjusting of the packaging speed and the bag length. 4. Double-side temperature control in heat-sealing, suitable for various kinds of packaging materials. 5. Low failure rate and long service life. 6. Easy operation and maintenance. 7. Safe and credible photoelectric detecting, giving complete trademark pattern. 8. Lot number being automatically printed on the bag, and can leave a little gap for easy tearing and convenience use. 9. All of models can be able to equip heat-printer device, the clear and good characters can be available. 10. Stainless steel material of the pump body/plated aluminum/polyethylene. 11. Stepless adjusting of the capacity in rated range 12. Viscid: With stirrer, it can package viscid substances with dregs. Suitable for upgrading fast food condiments 13. Packing material: Polyester/plated aluminum/polyethylene, BOPP/polyethylene, aluminum-foil/polyethylene, nylon/CPP. |
 |
| Item |
DXDL60 |
DXDB60 |
|
Packaging
speed Bag/min |
40~60 |
|
|
Range
of measurement ml |
1~50 |
1~100 |
|
Bag
size mm |
L: 50~120, W 60~85 |
L:80~145, W:75~100 |
|
Source
voltage |
3-phase and four-wire system 380V/50Hz |
|
|
Power Kw |
0.86 |
|
|
Machine
weight
Kg |
175 |
|
|
Dimension
mm |
625〜751〜1558 |
|
