SK6, SK10, SK20 Hydraulic Pressure Tablet Press


Performance Characteristics:

  the hydraulic Yaji electrical use "PLC" programming control, all moves can be time regulation. 209,000 full use of hydraulic components manufactured imports, double, to suppress, product processing powder high, repression density is good, efficient production, the key position to control the use of mechanical and electrical double, all moves can be produced through the Plc to the best state.


  Main Technical Specifications:


Type

SK6

SK10

SK20

Work pressure

6T

10T

20T

Up-Max  itinerary

60

110

110

Loading height

35

70

80

Down-Max  itinerary

70

115

115

Production number/m

40

32

20

Product errors(mm)

¡À0.05

¡À0.05

¡À0.05

Motor

1.5KW

3KW

4KW

Overall size(LxWxH)

1500x700x700

1950x8500x9500

2100x1000x1050

Weight

350KG

920KG

1000KG
